Plate Magnet Wire

The enameled rectangular copper wire produced by our company can be applied to the winding coils of drive motors, transformers, motors, generators and various electrical devices of new energy vehicles. If you are searching for dependable enameled wire supplier, don't hesitate to contact us to get the latest price!

Products

Copper Tube 
- By Types 
  -  Inner-grooved Tube
  -  Level Wound Tube
  -  Pancake Coil
  -  Insulated Copper Tube
- By Application 
  -  Air Conditioning Straight Tube
  -  Copper Water Tube
Copper Fittings 
Copper Plate & Sheet 
- Lead Brass Plate
Copper Strip & Roll 
Copper & Brass & Bronze Rod & Wire 
Copper Wire 
Copper Busbar 
Enameled Copper Wire 
NdFeB Permanent Magnet 
Brass Valves & Pipe Fitting 
- Brass Ball Valve 
  -  Brass Mini Ball Valve
  -  Brass Lockable Ball Valve JKL-279
  -  Brass Ball Valve JKL-9267
  -  Brass Ball Valve JKL-5262
  -  Brass Ball Valve with Strainer JKL-261
- Brass Gate Valve 
  -  Brass Gate Valve JKL-5117
  -  Brass Gate Valve JKL-5114
  -  Brass Gate Valve JKL-167
  -  Brass Lockable Gate Valve JKL-9118
  -  Brass Magnetic Lockable Gate Valve JKL-9119
  -  Brass Check Gate Valve JKL-9169
- Brass Check Valve 
  -  Brass Spring Check Valve
  -  Brass Swing Check Valve
  -  Brass Vertical Check Valve JKL-5425
- Brass Float Ball Valve 
  -  Brass Float Ball Valve JKL-5901
  -  Brass Float Ball Valve JKL-5906
- Brass Angle Valve 
  -  Brass Angle Valve(JKL-SJ-806)
- Brass Stop Valve 
  -  Brass Stop Valve JKL-317
  -  Brass Stop Valve JKL-318
  -  Brass Stop Valve JKL-385
  -  Brass Lockable Stop Valve JKL-316
- Brass Strainer 
  -  Brass Strainer JKL-607
- Brass Pressure Reducing Valve 
  -  Brass Pressure Reducing Valve JKL-737
- Brass Manifold 
  -  Integrated Brass Manifold
- Brass Bibcock 
  -  Brass Bibcock JKL-501
  -  Brass Bibcock JKL-502
  -  Brass Bibcock JKL-5541
- Brass Gas Valve 
  -  Brass Gas Ball Valve JKL-R60001
  -  Brass Gas Ball Valve JKL-R64001
- Brass Flanged Valve 
- Brass Fittings 
  -  Brass Fittings(JKL-4602)
Coper Wire Size 
- 3mm Wire
- 8mm Wire

Plate Magnet Wire Certifications

Plate Magnet Wire Performance Advantages

Excellent conductivity and thermal stability
Scratch resistance
Solvent resistance
Good resistance to heat dissipation when wound into a wire
High magnetic field efficiency

Plate Magnet Wire Application Fields

New Energy Drive Motor
Engine

Plate Magnet Wire Performance Parameter

Thermal level		Model		Specifications range	Standard
code	level	name	model	mm²	IEC	GB/T	NEMA	JIS
B	130	Class 130 polyester enamelled copper flat wire	QZ B-x/130	1.5mm²-15mm² 1.2:1≤Width width ratio≤8:1	60317	7095.7	-	*
F	155	Grade 155 polyester enamelled copper flat wire	QZ B-x/155	1.5mm²-15mm² 1.2:1≤Width width ratio≤8:1	60317-16	7095.3	-	*
H	180	Polyester imide enamelled copper flat wire, class 180	QZYB-x/180	1.5mm²-15mm² 1.2:1≤Width width ratio≤8:1	60317-28	7095.4	-	*
C	200/220	Grade 200 polyester imide / polyamide imide composite enamelled copper flat wire grade 220 polyamide imide enamelled copper flat wire	Q(ZY/XY) B-x/200QXYB-X/200	1.5mm²-15mm² 1.2:1≤Width width ratio≤8:1	60317-29	7095.6	MW36-C	*
C	240	Class 240 polyimide enamelled copper flat wire	QYB-x/240	1.5mm²-15mm² 1.2:1≤Width width ratio≤8:1	60317-47	7095.5	MW20-C	*
